Burnaby is our home city. Our shop sits on Douglas Road, and the bulk of the gate work we install in any given month is within a 10-minute drive of that address. Working primarily in one city for nearly two decades changes what you notice, which materials hold up, which short-cuts fail, which neighbourhoods favour which design language, and where the City permit process catches people off guard.
This post is the Burnaby-specific version of the driveway gate conversation. The fabrication itself is the same as anywhere else in Metro Vancouver, but the design choices, permit steps, and common failure modes are influenced by what we see locally. For the broader cross-Metro design discussion, swing versus slide, single versus double leaf, automation classes, our Vancouver driveway gates guide is the better starting point.
What Burnaby’s geography means for gates
Most of Burnaby is flatter than Coquitlam to the east and the steep side of West Vancouver to the north. The flat areas, Edmonds, Burnaby Heights east of Hastings, Capitol Hill below the rim, and most of Big Bend, make swing gates the simpler answer. The clearance issue that forces slide gates on steep Burke Mountain or Westwood Plateau driveways rarely shows up on a flat Burnaby Heights lot.
The exception is Burnaby Mountain, the SFU side, particularly UniverCity and the upper neighbourhoods of North Burnaby. Driveways up there have real grade, and the same slope considerations that drive design in Coquitlam apply to those projects.
For most Burnaby residential work, a single-leaf cantilever swing gate sized for 10 to 14 ft is the bread-and-butter installation. Double-leaf swings cover the wider openings (typically 14 to 20 ft total). Slide gates show up mostly on commercial properties along the Lougheed corridor, in the Production Way industrial area, and on light-industrial sites in Big Bend.
City of Burnaby permit and bylaw process
Burnaby’s permit system runs through the City’s permits and applications service. Most residential fence and gate work under 1.8 m height in standard zoning does not require a building permit, but several conditions trigger one:
- Gates over 1.8 m total height above the adjacent grade
- Anything within a setback that the zoning bylaw protects (front yard, exterior side yard on a corner lot)
- Heritage-designated properties anywhere in the City, Burnaby has a smaller heritage register than Vancouver, but Burnaby Heights and parts of Capitol Hill have heritage-designated character homes
- Strata-managed properties where strata council sign-off and possibly architectural control committee review apply
- Commercial and industrial sites where the gate is part of a fence or security enclosure
Practical advice from working in Burnaby year-round: confirm directly with the Building Permits Division (604-294-7130) before fabrication starts. The City has a clear permit review timeline but volume can stretch it during busy construction seasons. Building the permit timeline into the project schedule from day one avoids the situation where the gate is fabricated and waiting in the shop while the City processes the application.
For commercial properties, especially anything in the Big Bend area, expect zoning and setback rules to drive design, there are riparian setbacks and environmental protection lines along the Fraser River and a few protected creeks that affect where a gate can sit on the property line.
What styles work in which Burnaby neighbourhood
Different parts of Burnaby pull the design conversation in different directions.
Burnaby Heights and Hastings Sunrise
Older character homes from the 1920s through 1960s. The streetscape is mature trees, traditional front yards, and modest scale. A driveway gate that respects this context is usually a vertical-picket steel gate in matte black powder coat, it reads as a refined upgrade without fighting the existing character. Horizontal slat designs sometimes feel out of step in this neighbourhood unless paired with a contemporary home renovation.
Capitol Hill and Vancouver Heights
Mix of older character homes on the south slope and contemporary new builds on the rim with view orientations toward downtown Vancouver. New build clients consistently want horizontal slat infill or solid panel designs in matte black, often with stone or board-formed concrete pillars. Older homes get the vertical picket treatment. Capitol Hill is one of the strongest indicators of where Burnaby’s residential design language has gone in the last decade.
Brentwood and Edmonds
These are the highest-density redevelopment areas in Burnaby. Most new residential gate work here is on townhouse or duplex strata properties and follows the architectural-control-committee design standards. The gates tend to be lighter-spec because the strata is buying for many homes, but specifications still need to hit the durability bar, a strata gate cycles a lot more than a single-family gate.
Big Bend, Lougheed corridor, and Production Way
Commercial and light-industrial. Slide gates dominate, sized for delivery trucks (typically 20 ft single span or wider on commercial yards). Specifications are heavier, Class III commercial operators, durable powder coats over hot-dip galvanizing, and access control integrated with the property’s broader security system. Aesthetics matter less; function matters more.
Burnaby Mountain (UniverCity and surroundings)
The newer high-end residential neighbourhoods at the SFU end of Burnaby. Steeper grades, contemporary architecture, view-oriented siting. Design language is similar to the Coquitlam mountain neighbourhoods next door, modern matte black with horizontal slats or solid panels, automation standard, integrated access control. Slope considerations apply on a meaningful number of these projects.
Common Burnaby project failures and how to avoid them
Working in one city for nearly twenty years means we see the same failure modes recur. Three are worth flagging.
Under-built hinge post and footing
The most common gate failure we see, in Burnaby and everywhere else. A heavy gate applies a continuous lateral load on its hinge post, the post wants to tip toward the gate. If the post is too small or the footing is undersized, the post slowly tips and the gate sags. By the time it is noticeable, the only fix is to pull the post and re-set it on a proper footing.
The prevention: size the hinge post and footing for the gate’s actual weight and span. A 14 ft swing gate needs a structural hinge post (typically 4” × 4” or 4” × 6” steel) on a concrete footing 24” diameter and 4 ft deep, not 12” diameter and 18” deep, which is what cheap installations spec. We size every footing based on the gate before quoting.
Powder coat over bare steel on exterior gates
We have replaced many gates in Burnaby because the original installer skipped hot-dip galvanizing and applied powder coat directly over bare steel. Within five to ten years, rust shows through at every weld termination, every chip, and every fastener. The fix is stripping the entire gate, hot-dip galvanizing, and re-coating, which costs more than getting the duplex system right at fabrication.
Operator under-spec’d for cycle count
Residential operators are rated for 30 to 50 cycles per day. On a long Burnaby Heights driveway with a multi-vehicle household, 50 cycles a day is realistic, and a Residential Class I operator at the bottom of its capacity will burn out in 4 to 6 years. Spec’ing up to a Residential Class II or light commercial operator costs slightly more but lasts twice as long.
Working with our Burnaby shop
We are a 17-minute drive from most Burnaby properties, and we install gates locally most weeks of the year. Working with a fabricator in your own city has practical advantages, site visits are quick, install scheduling is flexible, and warranty service does not have to wait for a contractor coming up from Surrey or down from Squamish. The shop on Douglas Road also means we can show clients work in progress on the bench, which is harder for fabricators an hour away.
The other Metro Vancouver gate posts on this site cover the cross-city design conversation. This one is for the homeowner or contractor in Burnaby itself who wants to know what works locally.
For a quote on a specific Burnaby driveway gate project, request a quote, every property has its own dimensions, slope, and access conditions, and pricing only makes sense after a site visit.
